TAYMA Drilling Pipes – Engineered for Maximum Performance in Oil & Gas
Overview
The TAYMA Drilling Pipe Series is designed to meet the demanding requirements of modern oilfield drilling, including land rigs, swamp barge rigs, and offshore platforms. Manufactured to API Spec 5DP and Fearnley Procter NS-1 standards, TAYMA drill pipes deliver superior performance, exceptional durability, and high operational reliability in challenging downhole conditions.
Whether you are drilling shallow wells or deep reservoirs, TAYMA pipes ensure optimal torque transmission, efficient fluid circulation, and long service life. With advanced engineering, premium materials, and comprehensive options for connections and coatings, these pipes are trusted by drilling operators worldwide.
Key Features of TAYMA Drilling Pipe Series
-
API Certified Quality: All TAYMA drill pipes meet API Spec 5DP and Fearnley Procter NS-1 standards, guaranteeing consistent quality, reliability, and compliance with international drilling requirements.
-
Versatile Steel Grades: Available in high-performance grades including E75, X95, G105, S135, SS75, SS95, and SS105, suitable for diverse geological formations and operational demands.
-
Comprehensive Size Range: Standard diameters range from 2-3/8” to 6-5/8”, accommodating various wellbore dimensions and drilling programs.
-
Multiple Connection Options: Includes API, AOH, DSHT, and PAC connections for maximum compatibility with different rig systems and drilling tools.
-
Upset Types: Pipes are offered with IU, EU, and IEU upsets, allowing flexibility for torque and stress distribution in different drilling scenarios.
-
Standard Length Options: Range 2 (27–30 ft) and Range 3 (38–45 ft) are standard, with custom lengths available on request to optimize rig efficiency.
-
Hardbanding Options: Enhance wear resistance with Arnco, Tuboscope, or proprietary hardbanding solutions, reducing tool joint wear and extending operational life.
-
Optimized Internal Diameter: Ensures efficient drilling fluid flow, reducing pressure loss and minimizing potential for formation damage.
-
Heavy-Duty Construction: Engineered to withstand high torsional stress, bending loads, and fatigue under extreme drilling conditions.
Common Drilling Pipe Sizes and Specifications
| OD (inches) | Wall Thickness (inches) | Tool Joint OD (inches) | Weight (lb/ft) | Connection Types | Typical Steel Grades |
|---|---|---|---|---|---|
| 2-3/8 | 0.190–0.280 | 3 1/8–3 1/2 | 6.65–10.40 | API, AOH, DSHT | E75, G105 |
| 2-7/8 | 0.217–0.362 | 3 1/2–4 1/8 | 10.40–14.70 | API, AOH, DSHT | E75, X95, G105 |
| 3-1/2 | 0.254–0.362 | 4 1/8–4 3/4 | 13.30–20.50 | API, AOH, DSHT | X95, G105, S135 |
| 4 | 0.262–0.330 | 4 3/4–5 1/2 | 14.00–22.00 | API, AOH, DSHT | X95, S135 |
| 4-1/2 | 0.271–0.337 | 5 1/2–6 5/8 | 16.60–24.60 | API, AOH, DSHT | S135, SS95 |
| 5 | 0.276–0.362 | 6 5/8–7 | 19.50–27.90 | API, AOH, DSHT | S135, SS105 |
| 5-1/2 | 0.361–0.415 | 7–7 5/8 | 24.70–32.30 | API, AOH, DSHT | S135, SS105 |
| 6-5/8 | 0.362–0.500 | 8 1/4–8 5/8 | 27.70–47.60 | API, AOH, DSHT | S135, SS105 |
Applications
-
Land Rigs: Optimized for shallow to medium-depth drilling operations.
-
Swamp Barge & Marsh Rigs: Designed to withstand floating platform motions while ensuring drilling stability.
-
Offshore Rigs: Suitable for deepwater drilling with high torque and fatigue resistance.
-
Directional & Horizontal Drilling: Available with premium connections to handle high-stress directional well paths.
Why Choose TAYMA Drill Pipes?
✅ Proven Performance: Built on industry-proven designs and rigorously tested to ensure reliability under harsh oilfield conditions.
✅ Customization & Flexibility: A wide range of steel grades, diameters, wall thicknesses, and connections to meet your project’s exact specifications.
✅ Extended Service Life: Advanced steel alloys, heat treatment, and hardbanding reduce wear and fatigue, lowering long-term operational costs.
✅ Global Supply & Support: Fast delivery to worldwide locations, combined with full technical support, maintenance guidance, and aftermarket service.
✅ Integrated Oilfield Solutions: TAYMA provides a full suite of drilling equipment—drill bits, pipes, pipe handling systems, and rigs—for seamless compatibility and operational efficiency.
